RK3588:HD-3588V
New Generation of Ultra-Powerful Processors
HD-3588V adopts Rexchip Microelectronics new generation flagship octa-core processor RK3588, 8nm process, integrated quad-core Cortex-A76 and quad-core Cortex-A55, main frequency up to 2.4GHz
four-screen differential display
Support V-By-One, HDMI/eDP, LVDS, MIPI output, up to four screen heterodyne display, support heterogeneous splicing, the same display, can be applied to a variety of high-definition multi-screen interactive display scenes.
8K Ultra HD video decoding
Adopt Mali-G610 MC4 GPU, support 8K60FPS H.265/H.264/AV1/VP9/AVS2 video decoding
Support HDMI IN
Supports HDMI IN, up to 4K@60Hz resolution inputs
Supports SATA hard disk expansion
Integrated 1-way SATA 3.0 hard disk interface, compatible with Serial ATA 3.1 and AHCI revision 1.3.1. Supports speeds SATA 1.5Gb/s, SATA 3.0Gb/s, and SATA 6.0Gb/s.
Rich Expansion Interface
HD-3588V has a powerful expansion capability with 7×USB interface, 1×SATA interface, 4×UART+1×DEBUG+1×MCU, 5×IO expansion port
Multiple communication methods
Support Gigabit Ethernet, Wi-Fi 6 (2.4GHz+5GHz dual-band), Bluetooth 5.0, built-in PCI-e, optional 4G/5G module
Android 13
Powered by Android 13, for greater security and compatibility.
Model HD-3588V
CPU RK3588 octa-core 2.4GHz
GPU ARM Mali-G610 MC4
NPU 6 TOPs NPU
System version Android 13
Decoding capability Supports up to 8K@60Hz video decoding
Display
interface
V-By-One:3840*2160@60Hz
HDMI IN/OUT:3840*2160@60Hz
eDP:3840*2160@60Hz
LVDS:1920*1080
MIPI:1920*1200
Wi-Fi Wi-Fi 6(2.4GHz+5GHz)
Bluetooth BT 5.0
Ethernet 1000Mbps
Optional 4G/5G
USB
TF interface
Extended Interface
1×USB 3.0 HOST, 1×USB 3.0 OTG, 5×USB expansion ports
3×UART, 1×DEBUG, 1×MCU, 1×SATA, 5×IO expansion
Messaging
software
Mobile APP⸺“LedArt”APP; Cloud Platform⸺XiaoHui Cloud; PC Software⸺LCD Player
