HD-VM1616C/0808C/0404C
  • Features
  • Specification
High Definition Inputs and Outputs
Support 1080P high-definition input and output, the device supports HDMI1.3 standard, each channel maximum support: 1080P@60Hz; input support HDCP
Device information At a glance
Support 1.8-inch full-color LCD screen and key functions, support for real-time display of equipment information, input and output signals, fast switching, access to pre-programming and preservation and other functions
Power failure memory function
Support power failure memory function, with power failure site protection, incoming calls automatically restore the state before the power off
Multiple control methods
Support infrared, keypad, RS232 center control docking ......
Model number HD-VM1616C HD-VM0808C HD-VM0404C
HDMI IN 16×HDMI 8×HDMI 4×HDMI
HDMI OUT 16×HDMI 8×HDMI 4×HDMI
Chassis Height 1U
Signaling delay 5ns(±1ns)
Control method Keypad/Serial/IR
Serial port parameter Control interface: DB9 / Baud rate and protocol Baud rate: 9600bps / Data bits: 8 bits / Stop bit: 1 bit, no parity bit / Serial control port structure: 2=TX, 3=RX, 5=GND
Supported Resolutions Maximum support 1920×1080@60Hz
Power External power supply, AC:180V-240V 50/60Hz, DC:12V/2A
Storage ambient temperature -20°C ~ +60°C
Operating temperature 0℃-50℃
Humidity level 5%~ 75%
