Allwinner H723：HD-723D
  • Features
  • Specification
High-performance quad-core processor
Adopts Allwinner H723 processor, equipped with quad-core Cortex-A53 CPU and Mali-G31 GPU, with a main frequency up to 1.4GHz
Android 14
Equipped with Android 14 operating system, it runs faster with enhanced security and compatibility
1080P FHD high-definition display
Supports LVDS/MIPI display interfaces, 1920×1080@60Hz high-definition resolution, delivering clear and delicate images
Supports HDMI IN
Onboard 1-channel HDMI IN interface, supports 1080P@60Hz video signal input, perfect compatibility with horizontal and vertical screen display. It integrates audio input synchronously to adapt to diverse application scenarios
Diverse program transmission methods
Supports multiple program transmission methods including Wi?Fi, USB flash drive, TF card, LAN and optional 4G, enabling flexible and convenient program updates
More practical functions
Interface Overview
Model
 HD-72D
CPU
Quad-core 1.4GHz
System version
Android 14.0 + HUIDU OS
Image display
1080P@60Hz
Display interface
LVDS：1920*1080@60Hz
MIPI：1920*1080@60Hz
Wi-Fi
Wi-Fi 6（2.4GHz）
LAN
100Mbps
Bluetooth
BT 5.2
Optional 4G/5G
4G (Circumscribed)
HDMI Input
1×HDMI IN
TF interface √
Extension interface
1×USB 2.0 HOST，1×USB 2.0 OTG，
1×USB pin header，1×UART，1×DEBUG，5×GPIO
Messaging
software
Mobile APP⸺“LedArt”APP; Cloud Platform⸺XiaoHui Cloud; PC Software⸺LCD Player
