| Product Model |
HD-RP375
|
| Loading capacity |
98,000 pixels (384 × 256)
|
| Data output | 6 group of RGB |
| HUB interface |
3×HUB75E
|
| Scanning | Static~1/128 |
| Point-by-Point Correction | √ |
| Rotate animation | √ |
| Smart Settings | √ |
| Mapping | √ |
| Light Board Numbering | √ |
| Monitoring Function | √ |
| Row/Column Extraction | √ |
| Non-Rectangular Loading | √ |
| Dual Program Backup | √ |
| Input Voltage Range |
90Vac - 264Vac
|
| Rated Input Voltage Range |
100Vac - 240Vac
|
| Peak Output Power | 65W |
| Rated Output Current | 13A (Peak Output Current Up to 15A) |
| Rated Output Voltage |
4.2V
|
| Operating Temperature (℃) |
-20℃~+50℃
|
