Maximum Loading Capacity 2.6 Million Pixels

Maximum width is 16,384 pixels or maximum hight 4,096 pixels

New Platform, Super Hard Decoding

Support multi-channel video window playback, Support up to 2-channel 4K or 6-channel 1080P or 10-channel 720P or 20-channel 360P

Mobile APP Wireless Control

Equipped with 5GHz & 2.4GHz Wi-Fi, Support mobile APP update programs

Support Synchronized Playback of HDMI Signals

Switch between different modes with one click,Support PIP/POP

Support USB Playback

Supports playback of videos and pictures from USB flash drives

HDMI Splicing Display

Internet Remote Cluster Control

Support 4G/5G(optional), LAN and Wi-Fi connect

Rich Interfaces

Rich interfaces to meet different functional requirements

Model	A6L	A5L	A4L	A3L
Loading capacity	2.6 million pixels	1.3 million pixels	655,350 pixels	655,350 pixels
Max. width	4096 pixels	16,384 pixels	16,384 pixels	8192 pixels
Memor	64GB	16GB	16GB	16GB
External expanding	Max. 128GB	Max. 128GB	Max. 128GB	Max. 128GB
Video hard decoding	4K	4K	4K	4K
Video signal input	-	1×HDMI	1×HDMI	-
HDMI cascade	-	√	-	-
Streaming media	-	√	√	√
LAN	100Mbps	1000Mbps	1000Mbps	100Mbps
Wi-Fi control	5GHz+2.4GHz	5GHz+2.4GHz	5GHz+2.4GHz	2.4GHz
Screen casting	Optional	Optional	-	-
USB playback	√	√	√	√
Cloud management	√	√	√	√
4G/5G module	Optional 4G	Optional 4G/5G	Optional 4G/5G	Optional 4G
External sensor	1 channel	2 channel	2 channel	2 channel
Source suppor	Video, pictures, text, animated words, clock, streaming, timing, counting, weather, tables, etc.
