Receiving Card HD-R512S for Full Color LED Display - Shenzhen Huidu Technology Co., Ltd
HD-R512S is LED Screen receiver both Sync and Async LED display controller
Interface: 12 HUB75E Output and 2 Gigabit Ethernet port output
Recommended loading range：192 pixels in width (For modules lower than 16 scan) or 128 pixels in width (For modules higher than 16 scan)
Highly can use all interfaces
Sender:C15C/C35C/A3/A4/A5/A6/VP210/VP420/VP620/VP820/VP1220/VP1620/VP1240/VP1640
Certification:CE/FCC/ROHS
Huidu Technology receiving card HD-R512S is a universal receiving card that support asynchronous sending card, synchronous sending card and all-in-one video processor , integrate 12 hub75E interfaces, no HUB board is required, and can be directly connected to various HUB75 interface modules.
Support various conventional drive chips and PWM chips, It supports static screen and any scanning mode between 2~64 scan; at the same time, it also supports data group exchange and data group offset function, which is used for debugging of irregular-shaped LED display.
R512S has 2 Gigabit Ethernet ports, and does not distinguish between import and export. It supports multiple R512S splicing to control various medium, large and large full-color LED displays.
